HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Housing Material:
-
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
3
Contact Tail Length:
-
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.295" (7.50mm)
Material Flammability Rating:
-
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
6A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
150 V
Torque - Screw:
-
standardLeadTime:
10 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Solder Retention
Mounting Type:
Surface Mount
Color:
White
Series:
COMBICON PTSM
Positions Per Level:
3
Packaging:
Bulk
Header Orientation:
Vertical
Current - UL:
5 A
Pitch:
0.098" (2.50mm)
ECCN:
EAR99
Contact Material:
-
Connector System:
COMBICON PTSM
Number of Contacts:
3
Orientation:
Straight
Housing Material:
Polyamide
Shrouded/Unshrouded:
Shrouded
Series:
PTSM
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
2.5mm
Current:
6A
Number of Rows:
1
Standards/Approvals:
cULus Recognised E60425-20110108, DIN EN 61340-5-1 (VDE 0300-5-1): 2008-07, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, UL Recognised E118976-20130619, VDE 40048497
Voltage:
160 V
Contact Plating:
Nickel, Tin
Pitch:
2.5mm
Termination Type:
Solder
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Solder
