HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
Screwless - Push-In Spring
Housing Material:
-
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Plug, Female Sockets
Number of Positions:
5
Contact Tail Length:
-
Wire Gauge or Range - mm²:
2.5mm²
Plug Wire Entry:
180°
Insulation Height:
-
Material Flammability Rating:
-
Package:
Bulk
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
-
Number of Levels:
1 (Mate), 2 (Input)
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
14 Weeks
Contact Mating Finish:
Tin
Ingress Protection:
-
Features:
Mating Flange, Retention Latches
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON TFKC
Positions Per Level:
5 (Mate), 10 (Input)
Header Orientation:
-
Current - UL:
16 A
Pitch:
0.200" (5.08mm)
ECCN:
EAR99
Contact Material:
-
Housing Material:
Polyamide
Number of Contacts:
10
Series:
TFKC 2
Colour:
Green
Length:
25.7mm
Current:
16A
Width:
35.2 mm
Depth:
22.1mm
Number of Rows:
1
Standards/Approvals:
RoHS, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, cULus Recognised (E60425-20101209), VDE (40048497), REACH, ISO 6988:1985-02, IEC 60512-9-1:2010-03, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, UL Recognised (E118976-20130619), IEC 60068-2-6:2007-12, IEC 60999-1:1999-11, IEC 60068-2-70:1995-12
Voltage:
320 V
Termination Type:
Push-in Spring
Pitch:
5.08mm
Product Type:
PCB Connector
Connector Gender:
Female
Mount Type:
Screw
