Shrouded/Unshrouded:
Shrouded
Row Pitch:
10.16mm
Housing Material:
Polyamide
Tail Pin Length:
4mm
Connector System:
COMBICON PC 6 hybrid
Number of Rows:
1
Contact Plating:
Silver
Product Type:
PCB Header
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Female
Standards/Approvals:
EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-27:2008-02, IEC 60068-2-6:2007-12, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, UL 94 V0
Mount Type:
Wave Soldering Mount
Current:
76A
Orientation:
180°
Series:
IPC
Voltage:
1000 V
Termination Type:
Solder
Pitch:
10.16mm
Mating Pin Length:
4mm
Number of Contacts:
3
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Female Sockets
Number of Positions:
3
Contact Tail Length:
0.157" (4.00mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.535" (13.60mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
76A
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
7 Weeks
Contact Mating Finish:
Silver
Voltage - IEC:
1 kV
Ingress Protection:
-
Features:
Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON IPC
Positions Per Level:
3
Header Orientation:
90°, Right Angle, Under Board
Current - UL:
66 A
Pitch:
0.400" (10.16mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
