HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
-
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Plug Housing for Female Sockets
Number of Positions:
19
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-2.5mm²
title:
1808984
Plug Wire Entry:
180°
Insulation Height:
0.394" (10.00mm)
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
14-20 AWG
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
7 Weeks
Contact Mating Finish:
-
Voltage - IEC:
630 V
Ingress Protection:
-
Features:
Retention Latches (Non-Wire Side)
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON MSTBC
Positions Per Level:
19
Packaging:
Bulk
Header Orientation:
-
Current - UL:
10 A
Pitch:
0.200" (5.08mm)
Contact Material:
-
ECCN:
EAR99
Housing Material:
Polyamide
Number of Contacts:
19
Series:
MSTBC
Colour:
Green
Length:
25mm
Current:
12A
Width:
96.52 mm
Depth:
10mm
Number of Rows:
1
Standards/Approvals:
IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60068-2-70:1995-12, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, ISO 6988:1985-02, IEC 60664-1:2007-04, UL 94 V0, EN 60695-2-12, EN 60695-2-13, cULus Recognised Approval ID: E60425-19931011, VDE approval of drawings Approval ID: 40050694
Voltage:
320 V
Termination Type:
Crimp
Pitch:
5.08mm
Product Type:
PCB Connector
Connector Gender:
Female
