Shrouded/Unshrouded:
Shrouded
Row Pitch:
7.62mm
Housing Material:
Polyamide
Tail Pin Length:
3.9mm
Connector System:
COMBICON MSTB 2
Number of Rows:
1
Contact Plating:
Tin Plated
Product Type:
PCB Header
Maximum Operating Temperature:
110°C
Minimum Operating Temperature:
60°C
Contact Gender:
Male
Standards/Approvals:
ATEX, CCC, cULus, IEC 60079-7, IEC 60112, IEC 61984, IECEX, UL 94 V0
Mount Type:
Wave Soldering Mount
Current:
12A
Orientation:
Straight
Series:
GMSTBV
Voltage:
352 V
Termination Type:
Solder
Pitch:
7.62mm
Mating Pin Length:
3.9mm
Number of Contacts:
2
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
2
Wire Gauge or Range - mm²:
-
title:
1796665
Plug Wire Entry:
-
Insulation Height:
0.472" (12.00mm)
edacadModel:
1796665 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3645962
Manufacturer:
Phoenix Contact
Contact Tail Length:
0.154" (3.90mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
Explosion Proof, Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON GMSTBV
Positions Per Level:
2
Packaging:
Bulk
Header Orientation:
Vertical
Pitch:
0.300" (7.62mm)
Contact Material:
-
ECCN:
EAR99
