Housing Material:
Polyamide
Number of Contacts:
9
Series:
FKC 2
Colour:
Green
Length:
33.52mm
Current:
12A
Width:
55.24 mm
Depth:
15mm
Number of Rows:
1
Standards/Approvals:
cULus E60425-19931011, VDE 40050694, IEC 61984, IEC 60664-1:2007-04, IEC 60112, UL 94 V0, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2, DIN 46228-1, DIN 46228-4, EU RoHS, CHINA RoHS, EU REACH
Voltage:
320 V
Termination Type:
Push-in Spring
Pitch:
5.08mm
Product Type:
PCB Connector
Connector Gender:
Female
Mount Type:
Locking Jack
HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
Screwless - Push-In Spring
Operating Temperature:
-
Type:
Plug, Female Sockets
Number of Positions:
9
Wire Gauge or Range - mm²:
0.2-2.5mm²
Plug Wire Entry:
180°
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
300 V
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Features:
Ejector Latches, Retention Latches (Non-Wire Side)
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON FKC
Positions Per Level:
9
Packaging:
Bulk
Header Orientation:
-
Current - UL:
10 A
Pitch:
0.200" (5.08mm)
ECCN:
EAR99
