Shrouded/Unshrouded:
Shrouded
Row Pitch:
5.08mm
Housing Material:
Polyamide
Tail Pin Length:
3.5mm
Connector System:
COMBICON MSTB 2.5
Number of Rows:
1
Contact Plating:
Tin Plated
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
CSA 13631-2585951, cULus E60425-19931011, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, UL 94 V0, VDE 40050648
Mount Type:
Wave Soldering Mount
Current:
12A
Orientation:
Angled
Series:
SMSTB
Voltage:
32 V
Termination Type:
Solder
Pitch:
5.08mm
Mating Pin Length:
3.5mm
Number of Contacts:
12
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
12
Contact Tail Length:
0.138" (3.50mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.583" (14.80mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON SMSTB
Positions Per Level:
12
Header Orientation:
45°
Current - UL:
15 A
Pitch:
0.200" (5.08mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
