HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
Screwless - Leg Spring, Push-In Spring
Operating Temperature:
-
Type:
Plug, Female Sockets
Number of Positions:
9
Wire Gauge or Range - mm²:
-
title:
1701061
Plug Wire Entry:
180°
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
4A
Header Orientation:
-
Wire Gauge or Range - AWG:
20-28 AWG
Voltage - UL:
125 V
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Number of Levels:
1
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Black
Series:
MICRO-COMBICON FK-MC
Positions Per Level:
9
Packaging:
Bulk
Current - UL:
4 A
Pitch:
0.098" (2.50mm)
ECCN:
EAR99
Housing Material:
Polyamide
Number of Contacts:
9
Series:
FK-MC
Colour:
Black
Length:
19.05mm
Current:
4A
Width:
23.1 mm
Depth:
11.75mm
Number of Rows:
1
Standards/Approvals:
IEC 60999-1:1999-11, EN 60695-2-13, IEC 60512-1-1:2002-02, IEC 60512-13-5:2006-02, UL 94, EN 60695-2-12, UL Recognised Approval ID: E60425-20230810, JEDEC JESD 201, IEC 60664-1:2007-04, IEC 60068-2-82, IEC 60112, IEC 60512-1-2:2002-02, VDE approval ID: 40057836, cULus Recognised Approval ID: E60425-20230810, IEC 60068-2-70:1995-12, EN ISO 22479:2022-06, EN 60695-10-2, IEC 60512-13-2:2006-02
Voltage:
160 V
Termination Type:
Socket
Pitch:
2.5mm
Product Type:
PCB Terminal Block
Connector Gender:
Female
Mount Type:
Push-in
