Shrouded/Unshrouded:
Shrouded
Row Pitch:
5.08mm
Housing Material:
Polybutylene Terephthalate
Tail Pin Length:
3.4mm
Connector System:
COMBICON MC 1.5
Number of Rows:
1
Contact Plating:
Tin over Nickel
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
CSA, cULus, IEC 60068, IEC 60512, ISO 6988, VDE
Mount Type:
Solder
Current:
8A
Orientation:
Vertical
Voltage:
32 V
Termination Type:
Solder
Pitch:
5.08mm
Mating Pin Length:
3.4mm
Number of Contacts:
3
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polybutylene Terephthalate (PBT)
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
3
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.362" (9.20mm)
REACH Status:
REACH Unaffected
edacadModel:
1847628 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3605637
Manufacturer:
Phoenix Contact
Contact Tail Length:
0.134" (3.40mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON MCV
Positions Per Level:
3
Packaging:
Bulk
Header Orientation:
Vertical
Current - UL:
8 A
Pitch:
0.200" (5.08mm)
Contact Material:
-
ECCN:
EAR99
