HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Unshrouded
Number of Positions:
7
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.110" (2.79mm)
edacadModel:
1737064 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3606128
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Contact Tail Length:
0.260" (6.60mm)
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
11 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
250 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON PST
Positions Per Level:
7
Header Orientation:
90°, Right Angle
Current - UL:
10 A
Wire Gauge or Range - AWG:
-
Pitch:
0.138" (3.50mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
Connector System:
COMBICON PST 1
Tail Pin Length:
6.6mm
Number of Contacts:
7
Termination Type:
Solder
Housing Material:
Polyamide
Shrouded/Unshrouded:
Unshrouded
Series:
PST1
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
3.5mm
Current:
8A
Number of Rows:
1
Standards/Approvals:
cULus Recognised, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-82, IEC 60112, IEC 60664-1, JEDEC JESD 201, UL 94 V0
Voltage:
25 V
Contact Plating:
Tin Plated
Pitch:
3.5mm
Mating Pin Length:
6.6mm
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Wave Soldering Mount
