HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (2 Side)
Number of Positions:
11
Contact Tail Length:
0.154" (3.90mm)
Wire Gauge or Range - mm²:
-
title:
1753615
Plug Wire Entry:
-
Insulation Height:
0.472" (12.00mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON MSTBV
Positions Per Level:
11
Packaging:
Bulk
Header Orientation:
Vertical
Current - UL:
12 A
Pitch:
0.197" (5.00mm)
Contact Material:
-
ECCN:
EAR99
Shrouded/Unshrouded:
Shrouded
Row Pitch:
5mm
Housing Material:
Polyamide
Tail Pin Length:
3.9mm
Connector System:
COMBICON MSTB 2
Number of Rows:
1
Contact Plating:
Tin Plated
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
CSA 13631-2585951, cULus E60425-19931011, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70, IEC 60112, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, IEC 61984, ISO 6988, UL 94 V0, VDE 40050648
Mount Type:
Wave Soldering Mount
Current:
12A
Orientation:
Straight
Series:
MSTBV
Voltage:
32 V
Termination Type:
Solder
Pitch:
5mm
Mating Pin Length:
3.9mm
Number of Contacts:
11
Contact Material:
Copper Alloy
