Shrouded/Unshrouded:
Shrouded
Row Pitch:
3.5mm
Housing Material:
Liquid Crystal Polymer
Tail Pin Length:
2.6mm
Connector System:
COMBICON FMC 1
Number of Rows:
2
Contact Plating:
Tin over Nickel
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
cULus Recognised (E60425-20110128), DIN EN 61760-1, IEC 60068-2-58, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, ISO 6988, RoHS, UL 94 V0, VDE (40011723)
Mount Type:
Solder
Current:
8A
Orientation:
Straight
Series:
MCDN
Voltage:
160 V
Termination Type:
Solder
Pitch:
3.5mm
Mating Pin Length:
2.6mm
Number of Contacts:
14
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Operating Temperature:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
14
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
REACH Status:
REACH Unaffected
edacadModel:
1953761 Models
edacadModelUrl:
/en/models/2528164
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A per Position
Number of Levels:
2
Wire Gauge or Range - AWG:
-
Voltage - UL:
150 V
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
250 V
Features:
-
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON MCDN
Positions Per Level:
7
Packaging:
Bulk
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
ECCN:
EAR99
