HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
6
Wire Gauge or Range - mm²:
-
title:
1806261
Plug Wire Entry:
-
Insulation Height:
0.339" (8.61mm)
REACH Status:
REACH Unaffected
edacadModel:
1806261 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/2515009
Manufacturer:
Phoenix Contact
Contact Tail Length:
0.138" (3.50mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Ingress Protection:
-
Features:
Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON GMSTB
Positions Per Level:
6
Packaging:
Bulk
Header Orientation:
90°, Right Angle
Current - UL:
15 A
Pitch:
0.300" (7.62mm)
Contact Material:
-
ECCN:
EAR99
Connector System:
COMBICON MSTB 2.5
Tail Pin Length:
3.23mm
Number of Contacts:
6
Orientation:
0°
Housing Material:
Polyamide
Shrouded/Unshrouded:
Shrouded
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
7.62mm
Current:
12A
Number of Rows:
1
Standards/Approvals:
CSA 13631-2585951, cULus E60425-19931013, IEC 60068-2-27:2008-02, IEC 60068-2-6:2007-12, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, VDE 40050648
Voltage:
63 V
Contact Plating:
Tin Plated
Pitch:
7.62mm
Mating Pin Length:
3.23mm
Termination Type:
Solder
Product Type:
PCB Header
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Mount Type:
Wave Soldering Mount
