HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Female Sockets
Number of Positions:
3
Wire Gauge or Range - mm²:
-
title:
1969700
Plug Wire Entry:
-
Insulation Height:
1.264" (32.10mm)
REACH Status:
REACH Unaffected
edacadModel:
1969700 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/2526741
Manufacturer:
Phoenix Contact
Contact Tail Length:
0.157" (4.00mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
76A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
8 Weeks
Contact Mating Finish:
Silver
Voltage - IEC:
1 kV
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON IPCV
Positions Per Level:
3
Packaging:
Bulk
Header Orientation:
Vertical
Current - UL:
66 A
Pitch:
0.400" (10.16mm)
Contact Material:
-
ECCN:
EAR99
Connector System:
COMBICON PC 6 hybrid
Tail Pin Length:
4mm
Number of Contacts:
3
Termination Type:
Solder
Housing Material:
Polyamide
Shrouded/Unshrouded:
Unshrouded
Series:
IPCV
Contact Material:
Copper Alloy
Contact Gender:
Female
Row Pitch:
10.16mm
Current:
76A
Number of Rows:
1
Standards/Approvals:
cULus, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70:1995-12, IEC 60112, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60512-7:1993-08, IEC 60512-8:1993-01, IEC 60664-1:2007-04, IEC 61984, ISO 6988:1985-02, UL 94 V0, VDE
Voltage:
1000 V
Contact Plating:
Silver
Pitch:
10.16mm
Mating Pin Length:
4mm
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Wave Soldering Mount
