Shrouded/Unshrouded:
Shrouded
Row Pitch:
3.5mm
Housing Material:
Liquid Crystal Polymer
Tail Pin Length:
2mm
Connector System:
COMBICON DFMC 1
Number of Rows:
2
Contact Plating:
Tin Plated
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
cULus Recognised, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-70, IEC 60068-2-82, IEC 60112, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60512-9-1, IEC 60664-1, ISO 6988, JEDEC JESD 201, UL 94 V0, VDE
Mount Type:
Through Hole
Current:
8A
Orientation:
Straight
Series:
DMC
Voltage:
160 V
Termination Type:
Solder Mount
Pitch:
3.5mm
Mating Pin Length:
2mm
Number of Contacts:
36
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Termination Style:
Solder
Housing Material:
Liquid Crystal Polymer (LCP)
Operating Temperature:
-
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
36
Contact Tail Length:
0.079" (2.00mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.425" (10.80mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Number of Levels:
2
Wire Gauge or Range - AWG:
-
Voltage - UL:
150 V
Torque - Screw:
-
standardLeadTime:
22 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
250 V
Ingress Protection:
-
Features:
Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON DMC
Positions Per Level:
18
Packaging:
Bulk
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
Contact Material:
-
ECCN:
EAR99
