Housing Material:
Polyamide
Number of Contacts:
14
Series:
MCVR
Colour:
Green
Length:
10.4mm
Current:
8A
Width:
54.13 mm
Depth:
19.1mm
Number of Rows:
1
Standards/Approvals:
IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-70:1995-12, ISO 6988:1985-02, UL 94 V0, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2, CTI according to IEC 60112 600, CSA Approval ID: 13631, cULus Recognised Approval ID: E60425-20110128, VDE Approval ID: 40011723
Voltage:
160 V
Termination Type:
Screw
Pitch:
3.81mm
Product Type:
PCB Connector
Connector Gender:
Female
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M2
Wire Strip Length:
7mm
Type:
Plug, Female Sockets
Number of Positions:
14
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.14-1.5mm²
Plug Wire Entry:
90°
Insulation Height:
0.752" (19.10mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Wire Gauge or Range - AWG:
14-30 AWG
Voltage - UL:
300 V
Torque - Screw:
0.22-0.25 Nm (1.9-2.2 Lb-In)
standardLeadTime:
16 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
320 V
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON MCVR
Positions Per Level:
14
Header Orientation:
-
Current - UL:
8 A
Pitch:
0.150" (3.81mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
