Shrouded/Unshrouded:
Shrouded
Row Pitch:
5.08mm
Housing Material:
Polybutylene Terephthalate
Tail Pin Length:
3.9mm
Connector System:
COMBICON MSTB 2.5
Number of Rows:
1
Contact Plating:
Tin Plated
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
CSA, cULus, IEC 60068-2-70, IEC 60112, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, IEC 61984, UL 94 V0, VDE
Mount Type:
Solder
Current:
12A
Orientation:
Straight
Voltage:
32 V
Termination Type:
Solder
Pitch:
5.08mm
Mating Pin Length:
3.9mm
Number of Contacts:
17
Contact Material:
Copper Alloy
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Operating Temperature:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
17
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
edacadModel:
1755888 Models
edacadModelUrl:
/en/models/2511609
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
standardLeadTime:
6 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON MSTBVA
Positions Per Level:
17
Packaging:
Bulk
Header Orientation:
Vertical
Current - UL:
12 A
Pitch:
0.200" (5.08mm)
ECCN:
EAR99
