Phoenix Contact 1984109
Product Information
Series:
PT
Mounting Type:
Plug-In
Gender:
Female
Body Orientation:
Straight
Length:
38.5mm
Housing Material:
PA
Width:
14.6mm
Depth:
11.1mm
Number of Rows:
1
Pitch:
3.5mm
For Use With:
PCB Connector
Number of Contacts:
11
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M2
Wire Strip Length:
5mm
Type:
Plug for Unshrouded Header
Number of Positions:
11
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-1.5mm²
Plug Wire Entry:
90° and 180°
Insulation Height:
0.437" (11.10mm)
REACH Status:
REACH Affected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Wire Gauge or Range - AWG:
16-26 AWG
Voltage - UL:
300 V
Torque - Screw:
0.22-0.25 Nm (1.9-2.2 Lb-In)
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
400 V
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON PT
Positions Per Level:
11
Header Orientation:
-
Current - UL:
10 A
Pitch:
0.138" (3.50mm)
Number of Levels:
1
Contact Material:
-
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 1984109 on website for other similar products.
We accept all major payment methods for all products including ET10841164. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 1984109 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Headers, Plugs and Sockets category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 1984109. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 1984109.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET10841164 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET10841164.
Yes. We ship 1984109 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 1984109. The product pt, is a highly preferred choice for users. The product is available in plug-in configuration. In addition, female is the available "Gender" of the product. It has straight body orientation. Its accurate length is 38.5mm. The product also features robust pa housing material. Furthermore, the product is 14.6mm wide. The product comes in 11.1mm depth. It comes in 1 of rows. Moreover, the product is 3.5mm. The product is highly suitable for pcb connector. The product contains 11 contacts. It is assigned with possible HTSUS value of 8536.90.4000. The product is rohs3 compliant. Moreover, it has screw - rising cage clamp terminal style. The product also features robust polyamide (pa), nylon housing material. It is available in screw size of m2. The typical length of the wire strip is 5mm. It comes in plug for unshrouded header configuration. The product carries possible position value of 11. A 0.2-1.5mm² of wire gauge. It also a 90° and 180° plug wire entry. 0.437" (11.10mm) of insulation height. In addition, it is reach affected. It carries ul94 v-0 of material flammability rating. It is shipped in bulk package . Its typical moisture sensitivity level is 1 (unlimited). An IEC current of 8a. While 16-26 awg is its range or wire gauge. While 300 v is the typical voltage of the product. It carries torque - screw values of 0.22-0.25 nm (1.9-2.2 lb-in). It has a long 8 weeks standard lead time. The mating finish of the contact is tin. The nominal voltage of the product is 400 v. The product is available in free hanging (in-line) configuration. It has a classic green colour. The product combicon pt, is a highly preferred choice for users. It has 11 positions each level. The typical current includes 10 a. Moreover, the product is 0.138" (3.50mm). The product carries 1 levels. The product is designated with the ear99 code number.
