HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Termination Style:
Solder
Operating Temperature:
-
Type:
Header, Blade Pins, Shrouded (4 Side)
Number of Positions:
4
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
125A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
600 V
standardLeadTime:
13 Weeks
Contact Mating Finish:
Silver
Voltage - IEC:
1 kV
Features:
Mating and Mounting Flange
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON PC
Positions Per Level:
4
Packaging:
Bulk
Header Orientation:
90°, Right Angle
Current - UL:
115 A
Pitch:
0.591" (15.00mm)
ECCN:
EAR99
Shrouded/Unshrouded:
Shrouded
Row Pitch:
15mm
Housing Material:
Polybutylene Terephthalate
Tail Pin Length:
4.6mm
Connector System:
COMBICON PC 35 hybrid
Number of Rows:
1
Contact Plating:
Silver
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Gender:
Male
Standards/Approvals:
cULus Recognised, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60512-7:1993-08, IEC 60512-8:1993-01, IEC 60664-1:2007-04, IEC 61373:1999-01, ISO 6988:1985-02
Mount Type:
Wave Soldering Mount
Current:
125A
Orientation:
Straight
Series:
PC
Voltage:
1000 V
Termination Type:
Solder
Pitch:
15mm
Mating Pin Length:
4.6mm
Number of Contacts:
4
Contact Material:
Copper Alloy
