Connector System:
COMBICON MSTB 2.5
Number of Contacts:
18
Termination Type:
Screw
Housing Material:
Polyamide
Series:
MVSTBW
Sub Type:
PCB Connector
Contact Gender:
Female
Row Pitch:
5.08mm
Current:
12A
Number of Rows:
1
Standards/Approvals:
VDE, UL 94 V0, ISO 6988:1985-02, IEC 61984, IEC 60999-1:1999-11, IEC 60512-9-1:2010-03, IEC 60512-13-5:2006-02, IEC 60512-13-2:2006-02, IEC 60512-1-2:2002-02, IEC 60512-1-1:2002-02, IEC 60068-2-70:1995-12, IEC 60068-2-6:2007-12, EN 60695-2-13, EN 60695-2-12, EN 60695-10-2, cULus, CSA
Voltage:
32 V
Contact Plating:
Tin Plated
Pitch:
5.08mm
Product Type:
PCB Connector
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper Alloy
HTSUS:
8536.90.4000
RoHS Status:
RoHS Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M3
Wire Strip Length:
7mm
Type:
Plug, Female Sockets
Number of Positions:
18
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-2.5mm²
Plug Wire Entry:
270°
Insulation Height:
1.024" (26.01mm)
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-30 AWG
Voltage - UL:
300 V
Torque - Screw:
0.5-0.6 Nm (4.4-5.3 Lb-In)
standardLeadTime:
19 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Ingress Protection:
-
Features:
Retention Latches (Non-Wire Side)
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON MVSTBW
Positions Per Level:
18
Packaging:
Bulk
Header Orientation:
-
Current - UL:
15 A
Pitch:
0.200" (5.08mm)
ECCN:
EAR99
Contact Material:
-
