Connector System:
ScaleX
Number of Contacts:
20
Termination Type:
Solder
Housing Material:
Liquid Crystal Polymer
Shrouded/Unshrouded:
Shrouded
Series:
FP
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
0.8mm
Current:
1.7A
Number of Rows:
2
Standards/Approvals:
cULus Recognised E118976-20190703, DIN EN 61340-5-1, IEC 60068-2-82, IEC 60112, IEC 60512-4-1:2003-05, IEC 60512-5-2:2002-02, IEC 60664-1, JEDEC JESD 201, UL 94 V0
Voltage:
500 V
Contact Plating:
Gold over Nickel
Pitch:
0.8mm
Product Type:
PCB Header
Maximum Operating Temperature:
125°C
Minimum Operating Temperature:
-55°C
Mount Type:
Solder
Contact Finish - Mating:
Gold
Style:
Board to Cable/Wire
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Contact Finish Thickness - Post:
-
Number of Positions:
20
Contact Finish - Post:
Tin
edacadModel:
1053615 Models
Overall Contact Length:
-
title:
1053615
Insulation Height:
0.254" (6.45mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Shrouded - 4 Wall
Applications:
-
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/17938811
Contact Shape:
Rectangular
Contact Finish Thickness - Mating:
-
Voltage Rating:
-
Row Spacing - Mating:
-
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
8 Weeks
Current Rating (Amps):
1.7A
Contact Length - Post:
-
Pitch - Mating:
0.031" (0.80mm)
Ingress Protection:
-
Features:
Shielded, Solder Retention
Mounting Type:
Surface Mount, Right Angle
Series:
COMBICON FP
Packaging:
Tape & Reel (TR)
Mated Stacking Heights:
-
Contact Type:
Male Pin
Contact Material:
Copper Alloy
Insulation Material:
Liquid Crystal Polymer (LCP)
ECCN:
EAR99
