Contact Finish - Mating:
Tin
Style:
Board to Cable/Wire
Contact Finish - Post:
Tin
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
-
Number of Positions:
6
Overall Contact Length:
-
Insulation Height:
-
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Shrouded - 4 Wall
Applications:
-
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Contact Shape:
Square
Contact Finish Thickness - Mating:
-
Voltage Rating:
600VAC/DC
Row Spacing - Mating:
0.118" (3.00mm)
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Locking Ramp
Termination:
Solder
standardLeadTime:
16 Weeks
Current Rating (Amps):
12.5A per Contact
Contact Length - Post:
-
Pitch - Mating:
0.118" (3.00mm)
Ingress Protection:
-
Features:
Board Lock, Retention Clips
Mounting Type:
Surface Mount, Right Angle
Series:
Micro-Fit+ 218216
Packaging:
Tape & Reel (TR)
Mated Stacking Heights:
-
Contact Type:
Male Pin
Contact Material:
Copper Alloy
Insulation Material:
Liquid Crystal Polymer (LCP), Glass Filled
ECCN:
EAR99
Contact Material:
High Copper Alloy
Number of Contacts:
6
Orientation:
Right Angle
Housing Material:
Liquid Crystal Polymer
Shrouded/Unshrouded:
Shrouded
Series:
218216
Row Pitch:
3mm
Current:
12.5A
Number of Rows:
2
Standards/Approvals:
EU RoHS, IEC-62474, IPC 1752A Class C, IPC 1752A Class D, Low-Halogen, REACH SVHC
Voltage:
600 Vrms
Pitch:
3mm
Termination Type:
Surface Mount
Contact Plating:
Matt Tin
Product Type:
PCB Header
Maximum Operating Temperature:
125°C
Minimum Operating Temperature:
-40°C
Mount Type:
Surface
