Contact Finish - Mating:
Tin
Style:
Board to Cable/Wire
Contact Finish - Post:
Tin
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
39.4µin (1.00µm)
Number of Positions:
3
Overall Contact Length:
-
Insulation Height:
0.165" (4.20mm)
Voltage Rating:
50VAC/DC
REACH Status:
REACH info available upon request
Shrouding:
Shrouded - 4 Wall
Applications:
Automotive, General Purpose, Industrial
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
Insulation Color:
Red
Contact Shape:
Square
Mated Stacking Heights:
7.4mm
Insulation Material:
Polyamide (PA), Nylon, Glass Filled
Package:
Box
Row Spacing - Mating:
-
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
Vendor Undefined
Contact Finish Thickness - Mating:
39.4µin (1.00µm)
Fastening Type:
Push-Pull
Termination:
Solder
Current Rating (Amps):
Varies by Wire Gauge
Contact Length - Post:
-
Pitch - Mating:
0.049" (1.25mm)
Ingress Protection:
-
Features:
Pick and Place, Solder Retention
Mounting Type:
Surface Mount
Series:
Micro-Lock PLUS 505568
Contact Type:
Male Pin
Contact Material:
Brass
Base Product Number:
505568
ECCN:
EAR99
Connector System:
Wire to Board Signal
Orientation:
Vertical
Housing Material:
Polyamide
Shrouded/Unshrouded:
Shrouded
Series:
505568
Contact Material:
Brass
Distrelec Product Id:
304-62-480
Row Pitch:
1.25mm
Current:
1.5A
Number of Rows:
1
Standards/Approvals:
IEC 61249, RoHS
Voltage:
50 V
Contact Plating:
Tin Bismuth
Pitch:
1.25mm
Termination Type:
Surface Mount
Product Type:
PCB Header
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Mount Type:
Board
