Amphenol ICC (Commercial Products) G800LV306018DEU
Product Information
Contact Finish - Mating:
Gold
Style:
Board to Board
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Operating Temperature:
-25°C ~ 105°C
Contact Finish Thickness - Post:
Flash
Number of Positions:
2
Contact Finish - Post:
Gold
Shrouding:
Unshrouded
Overall Contact Length:
0.510" (12.95mm)
Insulation Height:
0.100" (2.54mm)
Voltage Rating:
250VDC
edacadModel:
G800LV306018DEU Models
Applications:
-
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/13683226
Insulation Color:
Black
Contact Shape:
Square
Mated Stacking Heights:
-
Insulation Material:
Polyamide (PA6T), Nylon 6T
Package:
Tape & Reel (TR)
Row Spacing - Mating:
-
Connector Type:
Header
Contact Length - Mating:
0.276" (7.00mm)
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Contact Finish Thickness - Mating:
Flash
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
12 Weeks
Current Rating (Amps):
3A per Contact
Contact Length - Post:
0.134" (3.40mm)
Pitch - Mating:
0.100" (2.54mm)
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Series:
BTB G800®
Contact Type:
Male Pin
Contact Material:
Copper Alloy
Base Product Number:
G800LV3
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search G800LV306018DEU on website for other similar products.
We accept all major payment methods for all products including ET20919510. Please check your shopping cart at the time of order.
You can order Amphenol ICC (Commercial Products) brand products with G800LV306018DEU directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Headers, Male Pins category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Amphenol ICC (Commercial Products) G800LV306018DEU. You can also check on our website or by contacting our customer support team for further order details on Amphenol ICC (Commercial Products) G800LV306018DEU.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET20919510 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Amphenol ICC (Commercial Products)" products on our website by using Enrgtech's Unique Manufacturing Part Number ET20919510.
Yes. We ship G800LV306018DEU Internationally to many countries around the world.
This is manufactured by Amphenol ICC (Commercial Products). The manufacturer part number is G800LV306018DEU. It has nice contact finishing of gold. Additionally, the product is designed with board to board Style. It is assigned with possible HTSUS value of 8536.69.4040. The product is rohs compliant. The product has -25°c ~ 105°c operating temperature range. Additionally, it features flash of post thickness. The product carries possible position value of 2. It has possible gold contact post finishing. Furthermore, a bespoke product features unshrouded. The product has a 0.510" (12.95mm) of overall contact lentgh. 0.100" (2.54mm) of insulation height. Moreover, the product has a nominal 250vdc voltage rating. It comes in 1 of rows. It carries ul94 v-0 of material flammability rating. In addition, black is the insulation color of the product. It has a typical square shape. It has a robust polyamide (pa6t), nylon 6t insulation material. It is shipped in tape & reel (tr) package . header Connector type offer robust functionality. It is 0.276" (7.00mm) contact mated. However, all is the Number of Positions Loaded. Its typical moisture sensitivity level is 1 (unlimited). However, flash is the "Contact Finish Thickness - Mating" of the product. Furthermore, push-pull is the Fastening Type of the product. The product features solder termination style. It has a long 12 weeks standard lead time. Additionally, the product's output is 3a per contact. 0.134" (3.40mm) is the given possible contact length (post) values. It has 0.100" (2.54mm) of pitch-mating value. The product is available in through hole configuration. The product btb g800®, is a highly preferred choice for users. It has typical contact type of male pin. The product is made from sturdy copper alloy materials. Moreover, it corresponds to g800lv3, a base product number of the product. The product is designated with the ear99 code number.
