GCT BC020-02-A-0200-0300-L-G

BC020-02-A-0200-0300-L-G GCT
GCT

Product Information

Contact Finish - Mating:
Gold
Style:
Board to Board
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
Flash
Number of Positions:
2
Contact Finish - Post:
Gold
edacadModel:
BC020-02-A-0200-0300-L-G Models
Overall Contact Length:
0.236" (6.00mm)
title:
BC020-02-A-0200-0300-L-G
Insulation Height:
0.039" (1.00mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Unshrouded
Applications:
-
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/12549946
Contact Shape:
Square
Mated Stacking Heights:
-
Voltage Rating:
250VAC/DC
Row Spacing - Mating:
-
Connector Type:
Header
Contact Length - Mating:
0.079" (2.00mm)
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Contact Finish Thickness - Mating:
Flash
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
9 Weeks
Current Rating (Amps):
1A per Contact
Contact Length - Post:
0.118" (3.00mm)
Pitch - Mating:
0.039" (1.00mm)
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Series:
BC020
Packaging:
Box
Insulation Material:
Liquid Crystal Polymer (LCP)
Contact Type:
Male Pin
Contact Material:
Copper Alloy
Base Product Number:
BC020
ECCN:
EAR99
Checking for live stock

This is manufactured by GCT. The manufacturer part number is BC020-02-A-0200-0300-L-G. It has nice contact finishing of gold. Additionally, the product is designed with board to board Style. It is assigned with possible HTSUS value of 8536.69.4040. The product is rohs3 compliant. The product has -40°c ~ 105°c operating temperature range. Additionally, it features flash of post thickness. The product carries possible position value of 2. It has possible gold contact post finishing. The product has a 0.236" (6.00mm) of overall contact lentgh. 0.039" (1.00mm) of insulation height. In addition, black is the insulation color of the product. In addition, it is reach unaffected. Furthermore, a bespoke product features unshrouded. It comes in 1 of rows. It carries ul94 v-0 of material flammability rating. It has a typical square shape. Moreover, the product has a nominal 250vac/dc voltage rating. header Connector type offer robust functionality. It is 0.079" (2.00mm) contact mated. However, all is the Number of Positions Loaded. Its typical moisture sensitivity level is 1 (unlimited). However, flash is the "Contact Finish Thickness - Mating" of the product. Furthermore, push-pull is the Fastening Type of the product. The product features solder termination style. It has a long 9 weeks standard lead time. Additionally, the product's output is 1a per contact. 0.118" (3.00mm) is the given possible contact length (post) values. It has 0.039" (1.00mm) of pitch-mating value. The product is available in through hole configuration. The product bc020, is a highly preferred choice for users. In addition, box is the available packaging type of the product. It has a robust liquid crystal polymer (lcp) insulation material. It has typical contact type of male pin. The product is made from sturdy copper alloy materials. Moreover, it corresponds to bc020, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
GCT EMEA LTD RoHS, REACH, TSCA, CA Prop65(Environmental Information)
pdf icon
1.00mm Header Product Spec(Datasheets)
pdf icon
BC020 Drawing(Product Drawings)
