Contact Finish - Mating:
Tin
Style:
Board to Cable/Wire
Contact Finish - Post:
Tin
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-
Contact Finish Thickness - Post:
100.0µin (2.54µm)
Number of Positions:
6
Overall Contact Length:
-
Insulation Height:
1.318" (33.48mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Shrouded - 4 Wall
Applications:
Automotive, General Purpose, Industrial
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Contact Shape:
Rectangular
Mated Stacking Heights:
-
Voltage Rating:
-
Row Spacing - Mating:
0.300" (7.62mm)
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Contact Finish Thickness - Mating:
100.0µin (2.54µm)
Fastening Type:
Latch Lock
Termination:
Solder
standardLeadTime:
26 Weeks
Current Rating (Amps):
-
Contact Length - Post:
-
Pitch - Mating:
0.300" (7.62mm)
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Board Guide, Mounting Flange
Mounting Type:
Panel Mount, Through Hole, Right Angle
Series:
MX150L 19437
Packaging:
Bulk
Insulation Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Contact Type:
Male Blade
Contact Material:
Copper Alloy
Base Product Number:
019437
ECCN:
EAR99
