Contact Finish - Mating:
Gold
Style:
Board to Board or Cable
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Contact Finish Thickness - Post:
-
Number of Positions:
24
Contact Finish - Post:
Tin
edacadModel:
15150242601000 Models
Overall Contact Length:
-
title:
15150242601000
Insulation Height:
0.167" (4.25mm)
Insulation Color:
Black
REACH Status:
REACH Unaffected
Shrouding:
Shrouded - 4 Wall
Applications:
-
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/8034462
Contact Shape:
Square
Contact Finish Thickness - Mating:
-
Voltage Rating:
-
Row Spacing - Mating:
0.050" (1.27mm)
Connector Type:
Header
Contact Length - Mating:
-
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
12 Weeks
Current Rating (Amps):
-
Contact Length - Post:
-
Pitch - Mating:
0.050" (1.27mm)
Ingress Protection:
-
Features:
Board Guide, Solder Retention
Mounting Type:
Surface Mount, Right Angle
Series:
har-flex®
Packaging:
Tape & Reel (TR)
Mated Stacking Heights:
-
Contact Type:
Male Pin
Contact Material:
Copper Alloy
Insulation Material:
Liquid Crystal Polymer (LCP)
ECCN:
EAR99
Contact Material:
Copper Alloy
Number of Contacts:
24
Orientation:
Angled
Housing Material:
Liquid Crystal Polymer
Shrouded/Unshrouded:
Shrouded
Series:
Har Flex
Contact Gender:
Male
Row Pitch:
1.27mm
Connector System:
Motherboard to daughtercard
Number of Rows:
2
Standards/Approvals:
UL 94 V-0
Contact Plating:
Gold Over Palladium Nickel
Pitch:
1.27mm
Termination Type:
Solder
Product Type:
Male Connector
Maximum Operating Temperature:
125°C
Minimum Operating Temperature:
-55°C
Mount Type:
Surface Mount
