Number of Levels:
1
Fused:
No
Termination Type:
Plug-In
Series:
PTS 1.5/S/1P-PE
Colour:
Yellow, Green
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
No
Standards/Approvals:
IEC 61984, EAC, DNV GL, cULus, cUL, CSA, Bureau Veritas, NK, IECEE CB, VDE, UL, LR
Cable CSA:
0.14 to 1.5 mm²
Maximum Wire Size AWG:
14 AWG
Product Type:
Earth Terminal Block
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-60°C
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Plug Receptacles, Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Operating Temperature:
-
Type:
Plug Connection
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-1.5mm²
Height (Max):
1.811" (46.00mm)
Housing Color:
Green, Yellow
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
8mm
Moisture Sensitivity Level (MSL):
Not Applicable
Length:
1.996" (50.70mm)
Wire Gauge or Range - AWG:
14-26 AWG
standardLeadTime:
6 Weeks
Terminal - Width:
3.5mm
Number of Levels:
1; Grounded
Features:
-
Mounting Type:
DIN Rail
Series:
CLIPLINE PTS
Packaging:
Bulk
ECCN:
EAR99
