Number of Levels:
1
Fused:
No
Termination Type:
Quick Connect
Series:
QTC 1.5
Colour:
Blue
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
24 AWG
Terminal Block Current:
17.5A
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
LR, NK, UL, EAC, IEC 60947-7-1, DNV GL, cULus, cUL, CSA, Bureau Veritas, ABS
Voltage:
800 V
Cable CSA:
0.25 to 1.5 mm²
Maximum Wire Size AWG:
16 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Feed Through
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
IDC
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
4
Wire Gauge or Range - mm²:
0.25-1.5mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
17.5 A
Wire Gauge or Range - AWG:
16-24 AWG
Voltage - UL:
600V
standardLeadTime:
16 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
800V
Features:
-
Color:
Blue
Series:
CLIPLINE QTC
Fuse Type:
-
Current - UL:
10 A
Number of Levels:
1
ECCN:
EAR99
