Number of Levels:
1
Fused:
No
Termination Type:
Solder
Series:
PT 6 BU
Colour:
Blue
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
8 AWG
Terminal Block Current:
41A
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
NK, LR, IECEX, IECEE CB Scheme, Bureau Veritas, ATEX, ABS, cULus Recognised, cUL Recognised, CSA, VDE, UL Recognised, RS, PRS, IEC 60947-7-1, EAC Ex, EAC, DNV GL
Voltage:
1 kV
Cable CSA:
0.5 to 10 mm²
Maximum Wire Size AWG:
8 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
110°C
Sub Type:
Feed Through
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.5-10mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
12mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
41 A
Number of Levels:
1
Wire Gauge or Range - AWG:
8-20 AWG
Voltage - UL:
600V
standardLeadTime:
8 Weeks
Terminal - Width:
8.2mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Blue
Series:
CLIPLINE PT
Packaging:
Bulk
Fuse Type:
-
Current - UL:
40 A
ECCN:
EAR99
