HTSUS:
8536.90.4000
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Ground, Earth
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-1.5mm²
title:
1452318
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
7mm ~ 8mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Number of Levels:
1
Wire Gauge or Range - AWG:
14-30 AWG
Voltage - UL:
-
standardLeadTime:
4 Weeks
Terminal - Width:
4.2mm
Disconnect Type:
-
Voltage - IEC:
-
Features:
-
Color:
Green, Yellow
Series:
CLIPLINE UT
Packaging:
Bulk
Fuse Type:
-
ECCN:
EAR99
Number of Levels:
2
Fused:
Yes
Minimum Operating Temperature:
60°C
Series:
UT
Colour:
Yellow, Green
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
IECEx, ATEX
Standards/Approvals:
ATEX, UL 94 V0, NFPA 130 (ASTM E 162,E 662,SMP 800C), IECEx, EU RoHS, EU REACH, DIN EN 50155, DIN EN 45545-2, cULus, China RoHS, cCSAus, CCC
Termination Type:
Push-in
Pitch:
4.15mm
Cable CSA:
1.5 mm²
Maximum Wire Size AWG:
16 AWG
Product Type:
Terminal Block
Maximum Operating Temperature:
110°C
