HTSUS:
8536.90.4000
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-1.5mm²
title:
1452265
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
7mm ~ 8mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
17.5 A
Number of Levels:
1
Wire Gauge or Range - AWG:
14-30 AWG
Voltage - UL:
1000V
standardLeadTime:
4 Weeks
Terminal - Width:
4.2mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Gray
Series:
CLIPLINE UT
Packaging:
Bulk
Fuse Type:
-
Current - UL:
15 A
ECCN:
EAR99
Number of Levels:
1
Minimum Operating Temperature:
60°C
Colour:
Grey
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
ATEX, IECEx, IECEx KEM 06.0027 U, KEMA
Standards/Approvals:
CCC, ATEX, CCSAUS, CHINA RoHS, cULus, DNV, ECLASS-13.0 27250101, ETIM 9.0 EC000897, EU REACH, EU RoHS, IECEX, UNSPSC 21.0 39121400
Voltage:
1000 V
Termination Type:
Screw
Pitch:
4.15mm
Cable CSA:
1.5 mm²
Maximum Wire Size AWG:
16 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
110°C
Terminal Block Current:
17.5A
