HTSUS:
8536.90.4000
Termination Style:
Push In
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.14-4mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
8mm ~ 10mm
Current - IEC:
24 A
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
600V
standardLeadTime:
10 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
-
Voltage - IEC:
800V
Features:
-
Color:
Pink
Series:
CLIPLINE PT
Fuse Type:
-
Current - UL:
20 A
Number of Levels:
1
ECCN:
EAR99
Number of Levels:
1
Terminal Block Current:
24A
Minimum Operating Temperature:
60°C
Series:
PT
Colour:
Pink
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
UKCA-EX, IECEx, EAC Ex, ATEX
Standards/Approvals:
cUL, CCC, BV, ABS, DNV, DIN EN 45545-2, cULus, CSA, VDE, UL 94 V0, UL, UKCA-EX, NK, NFPA 130, LR, IECEE CB Scheme, IEC 60947-7-1, EAC
Voltage:
80 V
Termination Type:
Push-in
Pitch:
5.2mm
Cable CSA:
2.5 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
110°C
Number of Positions:
1
