HTSUS:
8536.90.4000
Termination Style:
Push In
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
4
Wire Gauge or Range - mm²:
0.14-1.5mm²
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
8mm ~ 10mm
Current - IEC:
17.5 A
Wire Gauge or Range - AWG:
14-26 AWG
Voltage - UL:
600V
standardLeadTime:
7 Weeks
Terminal - Width:
3.5mm
Disconnect Type:
-
Voltage - IEC:
500V
Features:
-
Color:
White
Series:
CLIPLINE PT
Fuse Type:
-
Current - UL:
5 A
Number of Levels:
1
ECCN:
EAR99
Number of Levels:
1
Terminal Block Current:
17.5A
Minimum Operating Temperature:
60°C
Series:
PT
Colour:
White
Minimum Wire Size AWG:
26 AWG
Hazardous Area Certification:
IECEx, EAC Ex, ATEX
Standards/Approvals:
ABS, NK, CSA, BV, ATEX, EAC Ex, DNV, cULus, CCC, IECEX, IEC 60947-7-1, LR
Voltage:
50 V
Termination Type:
Push-in
Cable CSA:
1.5 mm²
Maximum Wire Size AWG:
16 AWG
Product Type:
DIN Rail Terminal Block
Maximum Operating Temperature:
110°C
Sub Type:
Feed Through Terminal Block
