Number of Levels:
1
Fused:
No
Termination Type:
Push-in
Series:
PT 4 OG
Colour:
Orange
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
10 AWG
Terminal Block Current:
32A
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
UL Recognised, VDE, NK, PRS, RS, ATEX, Bureau Veritas, CSA, cUL Recognised, cULus Recognised, DNV GL, EAC, IEC 60947-7-1, IECEE CB Scheme, IECEX, LR
Voltage:
800 V
Cable CSA:
6 mm²
Maximum Wire Size AWG:
10 AWG
Product Type:
Component Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Feed Through
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.2-6mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Box
Stripping Length:
12mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
32 A
Wire Gauge or Range - AWG:
10-24 AWG
Voltage - UL:
600V
standardLeadTime:
15 Weeks
Terminal - Width:
6.2mm
Disconnect Type:
-
Voltage - IEC:
800V
Features:
-
Color:
Orange
Series:
CLIPLINE PT
Fuse Type:
-
Current - UL:
30 A
Number of Levels:
1
ECCN:
EAR99
