Number of Levels:
1
Fused:
No
Termination Type:
Push-in
Series:
PT 2.5-QUATTRO-MT BU
Colour:
Blue
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Terminal Block Current:
20A
Hazardous Area Certification:
No
Standards/Approvals:
CSA, cUL, GOST, IEC 60947-7-1, LR, NK, RS, UL, ABS, Bureau Veritas
Voltage:
400 V
Cable CSA:
0.14 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
Knife Disconnect Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Disconnect
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Type:
Disconnect
Number of Positions:
4
Wire Gauge or Range - mm²:
0.14-4mm²
title:
3211676
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
20 A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-26 AWG
Voltage - UL:
300V
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Disconnect Type:
Switch, Knife
Voltage - IEC:
400V
Features:
-
Color:
Blue
Series:
CLIPLINE PT
Packaging:
Box
Fuse Type:
-
Current - UL:
20 A
ECCN:
EAR99
