Number of Levels:
1
Fused:
No
Termination Type:
Bolt
Series:
RT 3 Clipline
Colour:
Grey
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Terminal Block Current:
24A
Hazardous Area Certification:
No
Standards/Approvals:
IECEX, ATEX, CCC, cULus, EAC Ex, IEC 60947-7-1, IECEE CB, NEPSI, VDE
Voltage:
1 kV
Maximum Wire Size AWG:
14 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Feed Through
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Bolt and Nut
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
0.1-2.5mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Box
Stripping Length:
-
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
24 A
Wire Gauge or Range - AWG:
14-26 AWG
Voltage - UL:
600V
standardLeadTime:
15 Weeks
Terminal - Width:
12.3mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Gray
Series:
CLIPLINE RT
Fuse Type:
-
Current - UL:
30 A
Number of Levels:
1
ECCN:
EAR99
