Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UKH 70
Colour:
Grey
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
4 AWG
Terminal Block Current:
192A
Hazardous Area Certification:
IECEx SEV 12.0008 U, ATEX
Standards/Approvals:
VDE, UL, PRS, NEPSI, LR, IECEX, IECEE CB Scheme, IEC 60947-7-1, EAC Ex, EAC, DNV, cULus, cUL, CSA, CCC, ATEX
Voltage:
1000 V
Cable CSA:
16 to 95 mm²
Maximum Wire Size AWG:
3/0 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
110°C
Sub Type:
Feed Through
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
16-95mm²
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
24mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
192 A
Wire Gauge or Range - AWG:
3/0-6 AWG
Voltage - UL:
1000V
standardLeadTime:
15 Weeks
Terminal - Width:
20.3mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Gray
Series:
CLIPLINE UKH
Fuse Type:
-
Current - UL:
192 A
Number of Levels:
1
ECCN:
EAR99
