Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UKH 240
Colour:
Blue
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
2 AWG
Terminal Block Current:
415A
Number of Positions:
1
Hazardous Area Certification:
IECEx/ATEX
Standards/Approvals:
ATEX, CSA, cUL, cULus, DNV GL, EAC Ex, UL, RS, PRS, LR, IECEX, EAC, IEC 60947-7-1
Voltage:
1 kV
Cable CSA:
70 to 240 mm²
Maximum Wire Size AWG:
2 AWG
Product Type:
High Current Connector
Maximum Operating Temperature:
105°C
Sub Type:
High Current
HTSUS:
8536.69.8000
RoHS Status:
RoHS Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
70-240mm²
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
40mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
415 A
Number of Levels:
1
Wire Gauge or Range - AWG:
500MCM (kcmil)-2/0 AWG
Voltage - UL:
600V
standardLeadTime:
4 Weeks
Terminal - Width:
36.0mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Blue
Series:
CLIPLINE UKH
Packaging:
Bulk
Fuse Type:
-
Current - UL:
380 A
ECCN:
EAR99
