Orion Fans OD9238-24LB

OD9238-24LB Orion Fans
Orion Fans

Product Information

Material - Blade:
Polybutylene Terephthalate (PBT)
HTSUS:
8414.59.6590
RoHS Status:
ROHS3 Compliant
Width:
38.00mm
Power (Watts):
4.8 W
Air Flow:
78.0 CFM (2.18m³/min)
Approval Agency:
CE, cURus, TUV, UR
Voltage Range:
15 ~ 26VDC
Noise:
50.2dB(A)
Voltage - Rated:
24VDC
REACH Status:
REACH Unaffected
Bearing Type:
Ball
Operating Temperature:
-4 ~ 149°F (-20 ~ 65°C)
RPM:
3500 RPM
Lifetime @ Temp.:
60000 Hrs @ 45°C
Static Pressure:
0.420 in H2O (104.6 Pa)
Size / Dimension:
Square - 92mm L x 92mm H
Termination:
2 Wire Leads
standardLeadTime:
19 Weeks
Current Rating (Amps):
0.200A
Moisture Sensitivity Level (MSL):
Not Applicable
Ingress Protection:
-
Features:
Auto Restart
Weight:
-
Series:
OD9238
Material - Frame:
Polybutylene Terephthalate (PBT)
Packaging:
Box
Fan Type:
Tubeaxial
ECCN:
EAR99
Checking for live stock

This is manufactured by Orion Fans. The manufacturer part number is OD9238-24LB. The blades are constructed from robust polybutylene terephthalate (pbt) materials. It is assigned with possible HTSUS value of 8414.59.6590. The product is rohs3 compliant. Furthermore, the product is 38.00mm wide. The product features power and watts of 4.8 w. It has a 78.0 cfm (2.18m³/min) air flow rate. It is approved by ce, curus, tuv, ur. While the voltage range is 15 ~ 26vdc. It has noise values of 50.2db(a). It also exhibits voltage rating of 24vdc. In addition, it is reach unaffected. This has integrated with a ball, a bearing with long-lasting features. The product has -4 ~ 149°f (-20 ~ 65°c) operating temperature range. It provides maximum rpm up to 3500 rpm. This product offers longer life span for 60000 hrs @ 45°c. The product has a 0.420 in h2o (104.6 pa) static pressure. The product's diameters include square - 92mm l x 92mm h. The product features 2 wire leads termination style. It has a long 19 weeks standard lead time. Additionally, the product's output is 0.200a. Its typical moisture sensitivity level is not applicable. The splendid features of the product include auto restart. The product od9238, is a highly preferred choice for users. The frame of the product is made from highly durable polybutylene terephthalate (pbt) materials. In addition, box is the available packaging type of the product. The latest designed fan is a type of tubeaxial offering unmatchable applications. The product is designated with the ear99 code number.
