Contactor Application:
Power Switching
Coil Voltage:
24 V
Pole and Throw Configuration:
4
Width:
143 mm
Contact Current:
275A
Control Circuit Voltage Uc:
48 V
Operational Current Ie:
150A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-25°C
Length:
255mm
Standards/Approvals:
CSA C22.2 No 14, CSA C22.2 No 60947-4-1, EN 60947-4-1, EN 60947-5-1, EN/ISO 13849-1, IEC 60068-2-30, IEC 60335-1:Clause 30.2, IEC 60335-2-40:Annex JJ, IEC 60529, IEC 60695-2-1, IEC 60947, IEC 60947-1 Annex Q, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, UL 94, UL 60947-4-1
Number of Auxiliary Contacts:
2
Contact Voltage:
48V
Series:
LC1G
Depth:
193mm
Normal State Configuration:
4 NO
Auxiliary Contact Configuration:
1 NO/1 NC
Power Rating:
220W
Number of Poles:
4
