Contactor Application:
Resistive Load
Coil Voltage:
200 V
Pole and Throw Configuration:
3
Width:
438 mm
Contact Current:
2.1kA
Control Circuit Voltage Uc:
200 V
Function:
AC
Operational Current Ie:
2100A
Product Type:
Contactor
Maximum Operating Temperature:
40°C
Terminal Type:
Screw Clamp
Minimum Operating Temperature:
-5°C
Length:
332mm
Standards/Approvals:
IEC 60529, IEC 60335-1:Clause 30.2, IEC 60068-2-30, EN/ISO 13849-1, EN 60947-5-1, EN 60947-4-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 14, UL 60947-4-1, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, IEC 60947-1 Annex Q, IEC 60947, IEC 60695-2-1, IEC 60335-2-40:Annex JJ, UL 94
Series:
LC1F21
Depth:
238.6mm
Normal State Configuration:
3 NO
Contact Voltage:
200V
Power Rating:
2100W
Number of Poles:
3
