Contactor Application:
Resistive Load, Motor Control
Coil Voltage:
110 V
Pole and Throw Configuration:
3
Width:
309 mm
Contact Current:
630A
Control Circuit Voltage Uc:
110 V
Function:
AC
Operational Current Ie:
630A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Bolt Terminal
Minimum Operating Temperature:
-15°C
Length:
304mm
Standards/Approvals:
IEC 60947-1 Annex Q, UL 94, UL 60947-4-1, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, IEC 60947, IEC 60695-2-1, IEC 60529, IEC 60335-2-40:Annex JJ, IEC 60335-1:Clause 30.2, IEC 60068-2-30, EN/ISO 13849-1, EN 60947-5-1, EN 60947-4-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 14
Series:
CR1F
Depth:
255mm
Normal State Configuration:
3 NO
Contact Voltage:
110V
Power Rating:
335kW
Number of Poles:
3
