Contactor Application:
Resistive Load
Coil Voltage:
220 V
Pole and Throw Configuration:
3
Width:
519 mm
Contact Current:
2.6kA
Control Circuit Voltage Uc:
220 V
Function:
AC
Operational Current Ie:
2600A
Product Type:
Contactor
Maximum Operating Temperature:
40°C
Terminal Type:
Screw Clamp
Minimum Operating Temperature:
-5°C
Length:
382mm
Standards/Approvals:
IEC 60947, UL 94, UL 60947-4-1, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, IEC 60947-1 Annex Q, IEC 60695-2-1, IEC 60529, IEC 60335-2-40:Annex JJ, IEC 60335-1:Clause 30.2, IEC 60068-2-30, EN/ISO 13849-1, EN 60947-5-1, EN 60947-4-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 14
Series:
LC1F
Depth:
251mm
Normal State Configuration:
3 NO
Contact Voltage:
220V
Power Rating:
2600W
Number of Poles:
3
