Contactor Application:
Power Contactor
Coil Voltage:
96/127 V
Pole and Throw Configuration:
3
Width:
120 mm
Contact Current:
65A
Control Circuit Voltage Uc:
127 V
Function:
Multifunction
Operational Current Ie:
65A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Length:
172mm
Standards/Approvals:
CE, URS, UL, UKCA, RMRS, RCM, PRS, ISO 13849-1, IP20, IEC 61508-2, IEC61508, IEC 60947-4-1, IEC 60529, EAC, DNV, CSA, CCC, ABS
Number of Auxiliary Contacts:
4
Auxiliary Contact Configuration:
2 NO/2 NC
Mount Type:
Screw
Series:
3RT
Depth:
170mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
1kV
Power Rating:
90kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
