Contactor Application:
AC-3, AC-3e, Traction Contactor
Coil Voltage:
72 V dc
Pole and Throw Configuration:
3P
Width:
55 mm
Contact Current:
60A
Control Circuit Voltage Uc:
72 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
41A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Length:
114mm
Standards/Approvals:
EAC, UL, UKCA, RMRS, RCM, PRS, IEC 61508, IEC 60947-5-1, ABS, CCC, CE, CSA, IEC 60947-4-1, DNV
Number of Auxiliary Contacts:
4
Auxiliary Contact Configuration:
2 NO/2 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
178mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
690V
Power Rating:
18.5kW
Number of Poles:
3
Minimum Operating Temperature:
-40°C
