Contactor Application:
AC-3, Traction Contactor
Coil Voltage:
72 V dc
Pole and Throw Configuration:
4
Width:
61 mm
Contact Current:
40A
Control Circuit Voltage Uc:
72 V
Function:
Mirror Contact, Safety
Operational Current Ie:
20A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Spring Loaded
Length:
102mm
Standards/Approvals:
ABS, CCC, CE, CSA, DNV, EAC, IEC 60947-5-1, IEC 61508, PRS, RCM, RMRS, UKCA, UL, IEC 60947-4-1
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT25
Depth:
107mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
400V
Power Rating:
11kW
Number of Poles:
4
Minimum Operating Temperature:
-40°C
