Contactor Application:
AC-1, Traction Contactor
Coil Voltage:
24 V dc
Pole and Throw Configuration:
4
Width:
60 mm
Contact Current:
40A
Control Circuit Voltage Uc:
24 V
Function:
Mirror Contact, Safety
Operational Current Ie:
40A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Spring Loaded
Minimum Operating Temperature:
-40°C
Length:
102mm
Standards/Approvals:
IEC 61508, ABS, CCC, CE, CSA, DNV, EAC, IEC 60947-4-1, IEC 60947-5-1, PRS, RCM, RMRS, UKCA, UL
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT23
Depth:
107mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
7.5kW
Number of Poles:
4
