Contactor Application:
AC-3, AC-3e, Traction Contactor
Coil Voltage:
24/34 V dc
Pole and Throw Configuration:
3P
Width:
45 mm
Contact Current:
16A
Control Circuit Voltage Uc:
34 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
16A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Spring Loaded
Minimum Operating Temperature:
-40°C
Length:
70mm
Standards/Approvals:
RCM, IEC 60947-4-1, IEC 60947-5-1, IEC 61508, PRS, RMRS, UKCA, UL, ABS, CCC, CE, CSA, DNV, EAC
Number of Auxiliary Contacts:
1
Auxiliary Contact Configuration:
1 NC
Mount Type:
Surface
Series:
3RT2
Depth:
73mm
Normal State Configuration:
1 NC
Contact Voltage:
400V
Power Rating:
7.5kW
Number of Poles:
3
