Contactor Application:
Power Contactor
Coil Voltage:
24 V
Pole and Throw Configuration:
3
Width:
45 mm
Contact Current:
12A
Control Circuit Voltage Uc:
24 V
Function:
Multifunction
Operational Current Ie:
12A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Length:
102mm
Standards/Approvals:
EAC, IEC 60529, IEC 60947-4-1, IEC61508, IEC 61508-2, IP20, RCM, PRS, UL, UKCA, RMRS, ISO 13849-1, ABS, CCC, CE, CSA, DNV
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
107mm
Normal State Configuration:
NO/NC
Contact Voltage:
690V
Power Rating:
5.5kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
